C141-E090-01EN 3 - 7
3.3 Cable Connections
3.3.1 Device connector
The disk drive has the connectors and terminals listed below for connecting external devices.
Figure 3.7 shows the locations of these connectors and terminals.
• Power supply connector (CN1)
• ATA interface connector (CN1)
Figure 3.7 Connector locations
ATA
interface
connector
Mode
Setting
Pins
Power supply
connector (CN1)
