4.16 RTC battery 4 Replacement Procedures
PORTÉGÉ A600 Maintenance Manual (960-710) [CONFIDENTIAL] 4-41
Installing the RTC battery
To install the RTC battery, follow the steps below and refer to Figure 4-21.
1. Set the RTC battery to the RTC battery holder (INSULATOR RTC BATT) and
close the RTC battery holder while sticking the cover portion with the double-sided
tape.
CAUTION: Use a new RTC battery holder, when the cushion of the RTC battery holder
is broken.
2. Set (stick) the RTC battery holder (INSULATOR RTC BATT) in place.
3. Connect the RTC battery harness to the connector CN9300 on the system board.
