Appendices Appendix C Pin Assignments
C-40 [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710)
C.60 CN2760 System board interface connector (25-pin)
Table C-57 System board interface connector (25-pin)
Pin No. Signal Name Pin No. Signal Name
1 TMP3G-GND 2 TMP3G-SXP
3 GND 4 3GWAKE-S3N
5 GND 6 PLTRS1-E3N
7 GND 8 3GRST-S3N
9 3GRFON-S3N 10 GND
11 GND 12 ZUSB3G-E3N
13 ZUSB3G-E3P 14 GND
15 GND 16 3GGPDT-P3N
17 3GLED-E3P 18 GND
19 3GON-S3N 20 E3V
21 E3V 22 E3V
23 E3V 24 E3V
25 E3V
C.61 IS2620 SIM Card interface connector (12-pin)
Table C-58 SIM Card interface connector (12-pin)
Pin No. Signal Name Pin No. Signal Name
1 UIMPWR-E3V 2 UIMRST-E3P
3 UIMCLK-E3P 4 NC
5 GND 6 NC
7 UIMDAT-E3P 8 NC
9 NC 10 NC
11 NC 12 GND
1T GND 2T GND
