Appendices Appendix B Board Layout
B.14 PCIe MiniCard FPC (FMT3G*) View for PORTEGE R600 (Not used)
(front)
Figure B-
14
PCIe MiniCard FPC (F
MT3G
*) layout (front)
Table B-
14
PCIe MiniCard FPC
(F
MT3G
*) connector (
front
)
Number Name
CN2621 Mini Card Slot2 I/F connector
CN2760 System board I/F connector
IS2620 SIM Card I/F connector
B-16 [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710)
