Appendix C Pin Assignments Appendices
PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] C-39
PCIe MiniCard FPC (FSI3G*) for PORTEGE A600
C.59 CN2621 Mini Card Slot2 interface connector (50-pin)
Table C-56 Mini Card Slot2 interface connector (50-pin)
Pin No. Signal Name Pin No. Signal Name
1
NC
2
E3V
3
NC
4
GND
5
NC
6
NC
7
NC
8
UIMPWR-E3V
9
GND
10
UIMDAT-E3P
11
NC
12
UIMCLK-E3P
13
NC
14
UIMRST-E3P
15
GND
16
NC
17
NC
18
GND
19
NC
20
3GRFON-S3N
21
GND
22
PLTRS1-E3N
23
NC
24
E3V
25
NC
26
GND
27
GND
28
NC
29
GND
30
NC
31
NC
32
NC
33
NC
34
GND
35
GND
36
ZUSB3G-E3N
37
NC
38
ZUSB3G-E3P
39
E3V
40
3GGPDT-P3N
41
E3V
42
3GLED-E3P
43
GND
44
NC
45
NC
46
NC
47
NC
48
NC
49
3GWAKE-S3N
50
GND
1T GND 2T GND
