Barco R9004470 Projector User Manual



10. Layout menu
10.4.2 Rename a layout
Only custom created layouts can be renamed.
How to rename?
1. Press MENU to activate the menus.
2. Use the or key to select Window and press ENTER.
3. Use the or key to select Layout and press ENTER.
The layout services window opens.
4. Use the or key to select Rename and press ENTER.
The Rename layout location window opens.
5. Use the or key to select the layout to rename and press ENTER.
The edit layout name window opens. The rst character is selected.
6. Use the or key to change the selected character.
Use the or key to selected another character.
Note: Digits can be entered with the digit keys on the remote control or on the local keypad. When a digit is entered in that
way, the next character is selected automatically.
7. Press ENTER to save the new name.
Image 10-53
Image 10-54
Image 10-55
Image 10-56
10.4.3 Delete a layout
What is possible?
Custom created layouts can be removed from the projector memory.
How to delete?
1. Press MENU to activate the menus.
2. Use the or key to select Window and press ENTER.
3. Use the or key to select Layout services and press ENTER.
R59770017 FLM HD14 15/03/2010
107
