12. ALIGNMENT MENU
About this chapter
This chapter describes the alignment of the projector once the physical installation is finished. Via the software, the image will be
perfectly aligned on the screen.
Overview
•Overviewflow
• Orientation
• Lens adjustment
• Side keystone
• Warp geometry settings
• Contrast enhancement
• Blanking
• Gamma
• Internal pattern
• Color space
• ScenergiX
12.1 Overview flow
Overview
Level 1 Level 2 Level 3
Alignment
Orientation
Front Table
Front Ceiling
Rear Table
Rear Ceiling
Lens
Zoom/Focus
Shift
Mid position
Side keystone
Warp
Horizontal keystone
Vertical keystone
Rotation
Pincushion / Barrel
4 corners
Load file
Blanking
Top
Bottom
Left
Right
Reset
Contrast enhancement
