E. Specifications
Scan Frequencies pixel clock >162Mhz (up to QXGA @ 60Hz)
Network connection
10/100 base-T
On board display server
Ethernet control standard
remote control projector over ethernet via Projector Toolset
Ambient Temperature Max 40°C (104°F)
Lamp
3 kW Xenon
Warranty universal lamphouse: 750 Hrs
Lens Shift Vertical: -110% to +110%
Horizontal: -52% to +52%
(small differences exist per lens type)
(short throw lenses have less shift)
Lens encoders
On zoom and focus (with TLD lenses)
Throw Ratio Lens Throw ratio
TLD (HB) (0.8) 0.7
TLD (HB) (1.2 ) 1.03
TLD (HB) (1.6 - 2.0) 1.35 - 1.70
TLD (HB) (2.0 - 2.8) 1.70 - 2.42
TLD (HB) (2.8 - 5.0) 2.42 - 4.35
TLD (HB) (5.0 - 8.0) 4.35 - 6.95
ScenergiX Standard horizontal & vertical electronic edge blending
Dust filters dense, high quality microfilters available as spare kit, in a 6-pack & 24-pack
Noise Level
56 dBA (at 40°C)
Mains Voltage 200 - 240 V
Power consumption 3600 W
Power Dissipation
max 13300BTU/h
Weight
99 kg (220 lbs)
Dimensions WxLxH:
707 x 1025 x 548 mm
(27.8 x 40.3 x 21.5 inch)
incl. carrying handle + rigging points
Safety Regulations Compliant with UL1950 and EN60950
Safety Regulations Compliant with UL1950 and EN60950
Electromagnetic Interference complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A
Order Information Projector: R9004470
Spare lamp: R9854420
6-pack dust filters: R9454470
24-pack dust filters: R9454480
RGB HV module: R9854440
FLM/SLM adaptor plate: R9854490
FLM rigging kit: R9854500
FLM flight case: R9854510
Lenses
Lens Order nr
TLD (HB) 0.8 R9842040
TLD (HB) 1.2 R9840770
TLD (HB) 1.6 - 2.0 R9842060
TLD (HB) 2.0 - 2.8 R9842080
TLD (HB) 2.8 - 5.0 R9842100
TLD (HB) 5.0 - 8.0 R9842120
222 R59770017 FLM HD14 15/03/2010
