12. Alignment menu
The leakage area for this overlap is defined and will be excluded during black level adjustment.
How to adjust
1. Press MENU to activate the menus.
2. Use the ▲ or ▼ key to select Alignment and press ENTER.
3. Use the ▲ or ▼ key to select ScenergiX and press ENTER.
4. Use the ▲ or ▼ key to select Black level and press ENTER.
Image 12-111
Image 12-112
Image 12-113
Image 12-114
5. Adjust the black level of area A until the black level of area A, B and C are equal. Use the Adjust function All, Red, Green and
Blue in the Black level menu.
A
C
B
12
13
11
R
G
B
RGB
Image 1
Image 2
Image 12-115
Black level adjustment
Use the Reset function to bring all ScenergiX settings back to zero.
R59770017 FLM HD14 15/03/2010 143
