12. Alignment menu
Level 1 Level 2 Level 3
Gamma
Internal patterns
Checker board
Color bars
Convergence
Focus
Full screen black
Full screen blue
Full screen green
Full screen red
Full screen white
Hatch
Outline
Color space
Projector
EBU
SMPTE
Custom
ScenergiX
Status
White level
Black level
Show pattern
Reset
12.2 Orientation
What can be done?
The way of physical installation of t
he projector can be defined to the projector.
The following installation are possible:
• front/table
• front/ceiling
• rear/table
• rear/ceiling
Set up the correct orientation
1. Press MENU to activate the menus.
2. Use the ▲ or ▼ key to select Alignment and press ENTER.
3. Use the ▲ or ▼ key to select Orientatio
n and press ENTER.
4. Use the ▲ or ▼ key to select the correct orientation and press ENTER.
118
R59770017 FLM HD14 15/03/2010
