Serial Communication, cont’d
System 7SC • Serial Communication4-8
The syntax for setting a special function is __ *
X?
# where __ is the function number and
X?
is the value.
To view a function’s setting, use __#, where __ is the function number. In the following table the values of
the
X?
variable are different for each command/function. These values are given in the rightmost column.
Command/response table for special function SIS commands
Command ASCII Command Response
X?
values
(host to switcher) (switcher to host) and additional descriptions
Delay times
Power on delay 1 *
X?
# WarmUp*
X?
0 = 0 seconds,
1 = 2 seconds,
2 = 4 seconds,
... in 2 second steps up to
150 = 300 seconds (5 minutes).
Example: 1*8# WarmUp*08 Example: set a 16 second power on delay
Example: 1# WarmUp*023 Example: view the power on delay
setting.
Power off delay 2 *
X?
# CoolDown*
X?
0 = 0 seconds,
1 = 2 seconds,
2 = 4 seconds,... in 2 second
steps up to 150 = 300 seconds.
Example: 2*23# CoolDown*023 Example: set a 46 second power off
delay.
RGB delay (Triple-Action Switching) 3 *
X?
# RGBDly*
X?
0 = 0.0 seconds (default), 1 = 0.5
seconds, 2 = 1.0 seconds,
... in ½ second steps up to
10 = 5.0 seconds
Example: 3*7# RGBDly*07 Example: 3.5 second RGB delay
Room relays
Room relay 1 mode/timing 4 *
X?
# Rly1Tm*
X?
0 = toggle mode (press on/off),
1 = momentary,
1
/
8 second long,
2 = momentary, ¼ second long,
3 = momentary,
3
/
8 second long,
... in
1
/
8 second steps up to
16 = 2.0 seconds
Example: 4*15# Rly1Tm*15 Example: momentary, 1.875 sec. long
Room relay 2 mode/timing 5 *
X?
# Rly2Tm*
X?
0 = toggle mode (press on/off),
1 = momentary,
1
/
8 second long,
2 = momentary, ¼ second long,
3 = momentary,
3
/
8 second long,
... in
1
/
8 second steps up to
16 = 2.0 seconds
Example: 5*8# Rly2Tm*08 Example: momentary, 1.0 sec. long
Scaler settings
Scaler output sync format 6 *
X?
# SyncOut*
X?
0 = RGBHV (default)
1 = RGBS
2 = RGsB (sync on green, SOG)
Example: 6*1# SyncOut*1 Example: RGBHV sync output
Scaler output polarity 7 *
X?
# SyncPol*
X?
0 = H-/V- (default)
1 = H-/V+
2 = H+/V-
3 = H+/V+
Example: 7*1# SyncPol*1 Example: H-/V+ sync polarity
Blue screen (blue & sync output only) 8*
X?
# Blu*
X?
0 = off (default) (RGB & sync output)
1 = on (blue video & sync output only)
Example: 8*1# Blu*1 Example: blue & sync output for setup
