Extron electronic System 7SC Switch User Manual



A-5System 7SC • Reference Material
Part Numbers and Accessories
Included parts
These items are included in each order for a System 7SC switcher:
Included parts Replacement
part number
System 7SC (1) 60-340-01
Rubber feet (self-adhesive) (4)
Rack mounting kit (brackets and screws) (1) 70-155-01
IR Emitter (1) 70-283-01
Batteries for the IR 701 remote control (2)
9-pin male-to-male adapter (9-pin D GCM) (1) 26-128-01
3.5 mm, 5-pole captive screw connectors (11) 10-319-10
3.5 mm, 10-pole captive screw connectors (2) 10-319-11
UC 50’ (15 m) universal projector control cable 26-518-01
IEC power cord
Tweeker (small screwdriver)
System 7SC User’s Manual
System 7SC Windows-based
control/configuration program
Accessories
These items can be ordered separately:
Accessories Part number
IR Broadcaster 60-272-01
Current/display power sensor 60-271-01
IR 701 remote control 70-145-01
SCP 200 (gray, black, white) 60-338-01, -02, -03
SCP 250 (gray, black, white) 60-356-01, -02, -03
IR Emitter and shield 70-283-01
Dual IR Emitter and shield 70-283-02
UC 100’ (30 m) universal projector control cable 26-518-02
UC 200’ (61 m) universal projector control cable 26-518-03
