7: Setup Mode: Channel Configuration
WiBox® 2100E Device Server User Guide 54
uses the internally stored remote IP address to provide the most
significant bytes of the IP address. If the IP address entered is
0.0.0.0/0, the device server enters Monitor Mode.
For example, if the remote IP address already configured in the
unit is 129.1.2.3, then an example command string would be
C3/7. (This would connect to 129.1.2.3 and port 7.) You may
also use a different ending for the connection string. For
example, C50.1/23 would connect you to 129.1.50.1 and port 23.
If an IP address does not follow the first command string
character (which is "C"), the subsequent character string is
interpreted as the host name and domain to be used in DNS
lookup. This character string can include a destination port
number as well. The port number can be preceded by either a
forward slash (/) or a colon ( : ).
Table 7-6. Manual Connection Address Example
Command String Result if remote IP is 129.1.2.3 and remote port is 1234
C121.2.4.5/1
Complete override; connection is started with host 121.2.4.5,
port 1.
C5
Connects to 129.1.2.5, port 1234.
C28.10/12
Connects to 129.1.28.10, port 12.
C0.0.0.0/0
Enters Monitor Mode.
Cwww.lantronix.com/80
For example, Cwww.lantronix.com/80 would try to connect to the
Lantronix web server if the <hostname:domain>
(www.lantronix.com) is configured in the DNS server database.
