9. Network centric operations
WAN
LAN
RM : Remote control &
Management
P : projection area
M2 : Meeting room
M1 : Meeting room 1
A : SERVER
R : remote meeting attendee
V : streaming video data
M3 : Large conference room
Image 9-1
Typical iQ Pro network architecture
A server
RM Remote Control and Management
M1 Meeting room 1
M2 Meeting room 2
M3 Large screen conference room
P Projection area
R Remote meeting attendee
V Streaming Video data
Wireless LAN (point-to-point) is also possible (using the PCMCIA connection on the projector ) and comple-
ments the functionality of direct cabling.
9.1.2 Network functionality
What can be done ?
The network functionality allows the projector to perform several network functions thanks to network features which are required in
most corporate environments:
Control & Management : wireless/wired (remote) control and monitoring of the projector(s) thanks to a user-friendly GUI (the
Client software).
Diagnostics : diagnostics through a user-friendly GUI and automatic E-mail sending.
Easy file (MS PowerPoint,...) manipulation and projection using the DropZone interface.
Remote control of the projector by allowing the desktop to be shared over the network (the DropZone interface).
Streaming media : The pr
ojector’s onboard computer is streamingvideo data ready, i.e. allowing the decoding of video stream-
ing data coming from a server via the LAN.
