Barco H600 Projector User Manual



8. Advanced
On the screen appears now a slider box
Image 8-21
8. Use or , the numeric keys on the remote, or the keypad to change the Noise Reduction
8.4.2 Aspect ratio
Aspect ratios
The standard aspect ratio used in broadcast television is the 4:3 ratio. However, most of the DVD sources use nowadays the
widescreen 16:9 or even the Cinemascope
TM
2.35:1 aspect ratio.
Some DVD sources may even use the anamorphic 16:9 or anamorphic 2.35:1 to take advantage of the higher vertical resolution
offered by the 4:3 ratio. The “anamorphic” term means that the original wide screen image is squeezed in order to fit the 4:3 aspect
ratio.
4:3
16:9
2.35:1
Image 8-22
Common non- anamorphic aspect ratios in DVD sources
16:9
2.35:1
Image 8-23
Anamorphic aspect ratios in DVD sources
What can be done ?
The aspect ratio setting forces the projector to project an image using a defined aspect ratio :
•4:3
16:9
•5:4
•Auto
The s
ettings do not refer to the aspect ratio of the source !
88 R5976821 BARCO ICON 15/03/2007
