9. Network centric operations
The network centric projector may be configured in the same way as a standard PC to support :
- SNMP service : provides diagnostics, basic control via SNMP messaging
- Microsoft Exchange services: for scheduling of projector tasks.
- Web client : offers an alternative to the Client software through a user-friendly internet based
interface (includes almost the same features as the Client software)
See the Appendix “General guidelines on Network configuration” for general guidelines on how to enable
these services.
9.1.3 iCon server specifications
Specifications
• 2.6 GHz Pentium IV processor
1
• 1GB DDR RAM
• 40 GB Hard Disk storage
• Microsoft XP Operating System
• Barco Server Software for network communication between Server and clients
9.2 Control
Overview
• Description
• How to use the control manager?
• General
• The source selection screen
• The PiP screen
• Image settings
• Advanced control
9.2.1 Description
What can be done ?
The projector allows a software client (client PC) to communicate locally with the server and hereby control the projector’s settings,
in this case one has a point to point communication, image 9-2. The client PC or laptop communicating with the projector may be
locally installed or may be remote, communication may then happen over a LAN, ima
ge 9-3
The projector performs the role of Server while the PC acts as a Client within the system.
The control and management client software incudes the possibility to create groups of projectors and that way control a whole fleet
of projectors.
A
B
Image 9-2
point to point iQ Pro network communication
A facility manager’s desk
B projector area
1. the pentium IV socket is upgradeable
R5976821 BARCO ICON 15/03/2007 119
