Appendix G: Supported Video Input
Table G-1 (Continued). Video input (display video formats).
Mode Resolution Sync. Polarity (H/V) Refresh Rate (Hz) Set in EDID VESA/CSA Standard
Analog Digital*
SXGA 1280 x 1024 +/+ 85 85 X DMT
WXGA 1360 x 768 +/+ 60 22–60 — DMT
SXGA+ 1400 x 1050 -/+ 50 22–50 — CVT
SXGA+ 1400 x 1050 -/+ 60 60 — DMT
SGI 1600 x 1024 +/+ 60 60 — CVT
UXGA 1600 x 1200 +/+ 50 50 — CVT
UXGA 1600 x 1200 +/+ 60 60 X DMT
UXGAr 1600 x 1200 +/+ 50 50 — CVT
UXGAr 1600 x 1200 +/+ 60 60 — CVT
WSXGA 1680 x 1050 -/+ 60 60 — DMT
HDTVp 1920 x 1080 +/+ — 22–24 — CEA-861-E
HDTVp 1920 x 1080 +/+ 50 50 — CEA-861-E
HDTVp 1920 x 1080 +/+ 60 60 X CEA-861-E
WUXGAr 1920 x 1200 +/+ 50 22–50 — CVT
WUXGAr 1920 x 1200 +/+ 60 60 X DMT
NOTE: When set to auto (by default), the ServSwitch 4site Flex reads the EDID of the connected monitor and automatically
supports its resolution.
