9-3
MFC 4550/6550MC/7550MC
OP-US-5.0
FAX Options
Flowchart of an Incoming Call
2) FAX: ON
VOICE: EXT.
(External Answering Machine is ON.)
1) FAX: ON
VOICE: ON
If the caller stops speaking for 5 seconds while leaving a message, the machine will
go into fax receiving mode automatically.
Incoming Call
Fax reception is
activated by the
CNG Fax Tones
automatically .
MSG CTR OGM
is activated.
The caller must
press your
remote code to
activate the
machine.
The fax message
is received into
memory.
The caller leaves
a voice message
in digital memory
or hangs up.
The fax message
is received into
memory.
fax call
Auto dial
fax call
Manual
MEMORY MEMORY
The caller
can also
send a fax
Voice call
MEMORY
REMOTE
CODE
*51
(see page
6-14~17.)
Incoming Call
Fax reception is
activated by the
CNG Fax Tones
automatically.
The external TAD
OGM is activated.
The caller must
press your
remote code to
activate the
machine.
The fax message
is received into
memory.
The caller leaves
a voice message
on the external
TAD.
The fax message
is received into
memory.
fax call
Auto dial
fax call
Manual
EXT.
TAD
MEMORY
MEMORY
REMOTE
CODE
*51
(see page
6-14~17.)
Voice call
MEMORY
NOTE: OGM = outgoing message
GETTING STARTED MESSAGE CENTER MODE SETTINGS
