4.11 3G card 4 Replacement Procedures
PORTÉGÉ R700 Maintenance Manual (960-833) [CONFIDENTIAL] 4-29
4.11 3G card
Removing the 3G card
To remove the 3G card, follow the steps below and refer to Figure 4-16 to 4-18.
1. Disconnect the sound board FPC from the connector CN9670 on the sound board
and CN9570 on the system board.
Figure 4-16 Removing the sound board FPC
CN9670
CN9570
Sound board FPC
