Appendices Appendix C Pin Assignments
C-28 [CONFIDENTIAL] PORTÉGÉ R700 Series Maintenance Manual (960-833)
C.31 CN4630 USB interface connector (4-pin)
Table C- 31 USB interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 UP1VBS-E5V 2 ZUSBP1-E3N
3 ZUSBP1-E3P
4
GND
1T GND
2T
GND
3T GND
C.32 CN6000 Speaker interface connector (4-pin)
Table C- 32 Speaker interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 SPOTL-PXN 2 SPOTL-PXP
3
SPOTR-PXP
4
SPOTR-PXN
C.33 CN6050 Int-Mic interface connector (2-pin)
Table C- 33 Int-Mic interface connector (2-pin)
Pin No. Signal Name Pin No. Signal Name
1 DMICIN-PXP 2 XDMCLK-PXP
3 GND
C.34 J6051 Microphone connector (6-pin)
Table C- 34 Microphone connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1 EMICB-P2V 2 -
3 EMICB-P2V 4 EMICIN-PXP
5 A-GND 6 DETCTA-P4N
