Appendices Appendix C Pin Assignments
C-22 [CONFIDENTIAL] PORTÉGÉ R700 Series Maintenance Manual (960-833)
eSATA/HDMI/USB board (FULES*)
C.23 CN9640 System board interface connector (50-pin)
Table C- 23 System board interface connector (50-pin)
Pin No. Signal Name Pin No. Signal Name
1
E5V 2
E5V
3
E5V
4
E5V
5
E5V
6
USBON0-E5N
7
P5V
8
USBON1-E5N
9
USBOC0-E3N
10
P3V
11
USBOC1-E3N
12
1R8-P1V
13
ESATEN-P3P
14
DPBHPD-P3P
15
GND
16
ZUSBC8-E3N
17
ZUSBC8-E3P
18
GND
19
ZUSBP2-E3N
20
ZUSBP2-E3P
21
GND
22
ZSTRP5-P1N
23
ZSTRP5-P1P
24
GND
25
ZSTTP5-P1N
26
ZSTTP5-P1P
27
GND
28
XIDPBC-P1N
29
XIDPBC-P1P
30
GND
31
ZIDPB0-P1N
32
ZIDPB0-P1P
33
GND
34
ZIDPB1-P1N
35
ZIDPB1-P1P
36
GND
37
ZIDPB2-P1N
38
ZIDPB2-P1P
39
GND
40
IDBSCL-P3P
41
GND
42
IDBSDA-P3P
43
GND
44
HDMMDL-P3N
45
GND
46
GND
47
GND
48
GND
49
NC
50
PDROPV
1T
GND
2T
GND
