Product Description
Optional Accessory Kits
Several kits containing selections of accessories for connecting the Test Set to the Base
Station equipment are available from Agilent Technologies. These are described in the
following three sections.
Agilent Technologies E8300A 8935 Base Station Accessory Kit
The Agilent Technologies E8300A 8935 Base Station Accessory Kit (see Table 1-1)
supplies serial cables, RF cables, and adapters required to connect the Test Set for
testing Base Stations.
.
Table 1-1 E8300A Base Station Accessory Kit Contents
Part Part Number Quantity Use
Cable Assembly,
N(M) to N(M), 10-ft.
08921-61010 1 Connects the Base Station TX Antenna Port
to the Test Set RF IN/OUT port.
Cable Assembly,
SMA(M) to BNC(M), 10-ft.
08921-61021 2 Connects Base Station Even Second clock
and 19.6608-MHz clock to Test Set.
Cable Assembly,
SMA(M) to N(M), 12-ft.
E8300-61002 1 Connects the Base Station TX Test Port to
the Test Set ANT IN port.
Cable Assembly,
N(M) to N(M), 2-ft.
E8300-61005 1 Used as the calibration cable for Insertion
Loss test.
Null Modem Cable Assembly,
DB9(F) to DB9(F), 10-ft.
5182-4794 1 Connects the PC serial port to the Test Set
SERIAL 9 port.
Attenuator,
N(M) to N(F), 6-dB
0955-0819 2 Used for cable loss calibration routines.
Adapter,
SMA(F) TO N(M)
1250-1250 2 Used for Base Station TX Test Port Cable
calibration, adapts to a Type N attenuator.
Adapter,
N(F) to N(F)
1250-0777 1 Used for joining Type N cables
Adapter,
TNC(M) to N(F)
1250-2361 1 Used for TNC connections on some Base
Stations.
Velcro Cable Wrap 1400-2157 10 Used for securing and organizing cables for
transporting and during testing.
Verification Guide E8300-90001 1 Used as a checklist for connector kit
contents.
Transit Case E8300-61006 1 Organizes and transports connectors and
cables. Includes spaces for Option 001 parts.
Strain Relief Assembly E8300-61004 2 Reduces strain on connectors from cables.
Strain Relief Application Guide E8300-90005 1 Instructions for using strain relief
assemblies.
