Reference
Accessing Test Software Functions
Chapter 5
O:\Manuals\E6385A_Amps\Book\Reference.fm
98
SOFTWARE MENU Screen Overview
Pressing the front-panel Menu key will cause the Test Set to display the SOFTWARE
MENU screen (see Figure 5-1). This screen allows the user to configure and run custom
Test Software, access help, proceed with a paused procedure, or access additional test
screens.
Figure 5-1 SOFTWARE MENU Screen
Loads the Test Software. The first time
might require as longs as 20 seconds.
Once the Test Software is in internal
memory, it runs the test.
Continues a paused test.
Accesses the Test Set help screen.
See “Loading a Test
Procedure” on page 99.
See “Changing Test
Parameters” on page
103.
See “Changing
Pass/Fail Limits” on
page 106.
Setting Test Execution
Conditions is not used in
the Test Software.
Selects the menu list.
See “Saving/Deleting a
Procedure” on page 109.
