- 265 -
4. Memory Switch
Memory switch is a function to save the user selected settings into NV memory, where memory switch
setting will be held unless memory switch is changed.
Memory switch is changed by manual setting or by command in the memory switch change mode.
* Hereafter, memory switch is referred to as MSW.
4.1 Memory Switches
4.1.1 CT-S280
No.
Setting
OFF ON
MSW1-1 Power ON Info ● Valid Not send
MSW1-2 Buffer Size ● 4K bytes 45 bytes
MSW1-3 Busy Condition ● Full/Err Full
MSW1-4 Receive Error ● Print ? No Print
MSW1-5 CR mode ● Ignored LF
MSW1-6 Reserved ● Fixed ―
MSW1-7 DSR Signal ● Invalid Valid
MSW1-8 Reserved ● Fixed ―
MSW2-1
Reserved ― ● Fixed
MSW2-2
Reserved ● Fixed ―
MSW2-3
Spool Print ● Invalid Valid
MSW2-4
Full Col Print ● LineFeed WaitData
MSW2-5
Resume aft PE ● Next Top
MSW2-6
Reserved ― ● Fixed
MSW2-7
Reserved ● Fixed ―
MSW2-8
PNE Sensor ● Valid Invalid
MSW3-1
Reserved ● Fixed ―
MSW3-2
Reserved ● Fixed ―
MSW3-3
Parallel 31 Pin ● Valid Invalid
MSW3-4
Reserved ● Fixed ―
MSW3-5
Reserved ● Fixed ―
MSW3-6
Reserved ● Fixed ―
MSW3-7
CBM270 Mode Invalid ● Valid
MSW3-8
Resum Open Err ● Close Command
●: Factory setting
