Secure Perfect 6.1.1 User Manual 224
R
Read and Keypad-Type Reader
Only reader board door inputs and 20DI board input points can be shunted from a keypad. (To
identify a reader board door input, look for a default description that follows this format: 0001-1-01
Reader. To identify a 20DI board input point, look for a default description that follows this format: 0001-
1-01 DI.)
Follow the steps below to shunt alarm groups within a micro connected to a keypad and badge reader:
1. Click the start key on the keypad. The start key is labeled with either an asterisk <*> or a plus <+>
depending on the reader model.
2. Type one of the following:
0 - to turn monitoring off
1 - to turn monitoring on
3. Type the alarm group number (00 to 15) you want shunted.
4. Click the end key that is labeled with either a pound sign (#) or an <x>.
5. Present a valid badge to the reader.
6. Click the start key on the keypad again.
7. Type your Personal Identification Number (PIN) on the keypad.
8. Click the end key (<#> or <x>).
Reader
Device Menu
The Reader option opens the Reader Form that allows you to modify records that are automatically
generated when you define a micro as well as configure door functions, routing, schedules, and events.
Reader Access
Reports Menu
The Reader Access option opens the Reader Access Report Form that allows you to create a report
based on persons in the Secure Perfect system that have access to any of the specified readers.
Reader Assignment
This window displays when you click Assign or Assign Readers, enabling you to select and assign a
reader association. Only readers in the operators’ facilities are available for assignment by this operator.
• Select, and then click the right arrow to assign an available reader.
• Select, and then click the left arrow to unassign a reader.
Click OK to display results in the Assigned Readers windowpane.
