Secure Perfect 6.1.1 User Manual 35
Digital Input Status Configuration
Digital Input Status
Reference Topic:
Status Tab
Digital inputs are physical sensing devices, such as door sensors or motion sensors, used to monitor an
electronic contact connected to a micro. Refer to your micro installation for information on how to connect
a digital input device to the micro.
The Digital Input Status Form provides a snapshot of the current status in the micros (active or inactive)
and physical state (open or closed) of a digital input (contact). Once you have set up your digital inputs
and alarms, you will need to verify the accuracy of your configuration.
Digital Output Status Configuration
Digital Output Status
Reference Topic:
Status Tab
The Digital Output Status Form provides a snapshot of the current digital output status in the micros. A
digital output represents an external device, such as lights, sirens, and door strikes that may be
connected to the micro.
Digital Video Viewer Program Configuration
Digital Video Viewer Application
The Digital Video Viewer application can be accessed from the Operations menu and by clicking the
camera icon from the toolbar.
Refer to the Digital Video Viewer Help system for additional information and features of this
program, including window management, PTZ control, and event tagging.
