Secure Perfect 6.1.1 User Manual 67
Event Trigger Form Completion
Reference Topics:
Preset/Camera Tab
Readers Tab
Alarms Tab
Intrusion Zone Tab
The Event Trigger Form opens with the Preset/Camera tab displayed. An event consists of a camera and
either readers, alarms, or zone activity. A trigger causes an event or program routine to be executed,
depending on what options you set on the tabs of this form. Intrusion Zone activities can also trigger an
event.
Example: A camera begins recording in response to an invalid badge transaction. An alarm is recorded
in response to the badge transaction.
Element Description
Search
Click to display or change an existing record.
Add
Click to add a new record.
Delete
Select and then click to remove an Event Trigger record.
Description
Enter text up to 64 alphanumeric characters in length. The description should convey
specific information relating to a physical location, camera, reader, or state, such as.
Front Door Inv Badge Camera 1 Reader 1
You can assign a reader alarm or camera alarm or both and this can be reflected in
the description of the Trigger.
Save
Following the completion of applicable options for this record, click to save this
record. The selection results display in the columns of the form window on the right.
Facility Form
Reference Topic:
Facility Tab
Use this form to define facilities. Your database can be partitioned and related records can be grouped.
These groupings are called facilities. If facilities will be used, you must create Facility definitions in the
Secure Perfect system.
A facility option can be designated on MOST forms throughout the system and any number of
facilities can be defined.
Usually, the system administrator is assigned to all facilities. Operators can be assigned to one or more
facilities and can choose which facilities to be active at any given time. All records have the default Ignore
Facilities, which means the records are not under facility protection; therefore, those records are visible to
all operators.
For a shortcut menu to related forms, move the mouse pointer below the tab and click the right
mouse button.
