HP Omnibook XE3 (Technology Codes GE and GD) Removal and Replacement 2-15
Figure 2-10. Removing the Hard Disk Drive
5.
Loosen all four screws in the underside of the hard drive carrier (the carrier retains the screws),
then slide the drive back and up out of the case.
Figure 2-11. Removing the Hard Disk Carrier
Pin connector
