Attention: Before you change any switch settings or move any jumpers, turn off the server; then,
disconnect all power cords and external cables. See the safety information in “Important Safety
Information” on page 1 and “Guidelines for trained service technicians” on page 115. Do not change
settings or move jumpers on any system-board switch or jumper block that is not shown in this
document.
Administrator password
If an administrator password is set, you must type the administrator password for access to the full Setup
utility menu. You can use any combination of up to seven characters (A - Z,a-z,and0-9)forthe
password.
If you forget the administrator password, you can reset it after you change the position of the clear
CMOS jumper.
Resetting passwords
If you forget the power-on password or administrator password, you can move the clear-CMOS jumper
block on the system board to pins 2 and 3, to clear CMOS memory and bypass the power-on or
administrator password check. The jumper location is shown in the following illustration.
Microprocessor
Heatsink
Orientation
DIMMs
DIMMs
Table 23. System board jumpers
Jumper number Jumper name Jumper setting
JP1 Clear CMOS jumper 1
v Pins 1 and 2: Keep CMOS data
(default).
v Pins 2 and 3: Clear CMOS data
(including power-on password and
administrator password)
JP6 Boot block jumper 2
v Pins 1 and 2: Boot from primary
BIOS page (default) .
v Pins 2 and 3: Boot from backup
BIOS page.
204 ThinkServer ThinkServer RS210, Types 6531, 6532, 6533, and 6534: Hardware Maintenance Manual
