Operator’s Checkout Procedure
1760 Series Component Waveform/Vector Monitor User Manual
2-20
10S/DIV
FLAT
LUM
CHROM
DIFF
R--Y
SCH R--Y
F+L
F+L+C
Figure 2-9. Two-Line DIFF filter display of 5-step staircase signal.
VECTOR PHASE
FLAT
LUM
CHROM
DIFF
R--Y
SCH R--Y
F+L
F+L+C
Figure 2-10. Two-Line R---Y display of color bar signal.
