Using the Menus
1760 Series Component Waveform/Vector Monitor User Manual
3-12
VERTPOS
HORIZPOS
CLEAR
MENU
VOLT1 VOLT2 TRACK
∆ V
700 mV
VOLT
TIME
MARK
V+T
Left Center Right
WFM CURSOR
Figure 3-3. The WAVEFORM CURSOR menu.
VERTPOS
HORIZPOS
CLEAR
MENU
VOLT1 VOLT2 TRACK
∆ V
700 mV
VOLT
TIME
MARK
V+T
WFM CURSOR
VEC CURSOR
POLAR
MARK
CONTROL
VOLT
TIME
Voltage Cursor 1
Voltage Cursor 2
Timing Cursor 1
Timing Cursor 2
Figure 3-4. The VECTOR+WFM CURSOR menu with V+T selected.
