Using the Menus
1760 Series Component Waveform/Vector Monitor User Manual
3-17
When bezel buttons corresponding to NEXT FIELD,
ALT2FIELD
, or ALT4FIELDare pushed, a box
flashes momentarily around t he on-scre en labe l to
verify that the selection has been made.
Readout
The line select readout (in the upper left of the CRT) consists
of field followed by line number. When
15H is selected, the
readout also displays the range of line numbers. For exam-
ple, select
FIELD 1 and 15H, then rotate the LINE SEL control
to 34. The readout is field 1, lines 34to 48:
F1 34
F1 48
Line Select F
unctions
All menus are functional during line select operation. The
line select menu display disappears when another menu is
selected, but the selected line and field are displayed until the
line select menu is exited. (The field and line readout re-
mains in the upper left of the screen, and the line select LED
remains lighted to indicate this state.)
Lineselectcanalsobeusedwith
MULTIPLE displays of WA VE-
FORM, VECTOR
,andSCH. Sele cted displays appear on the
screen in the following order:
WAVEFORM, VECTOR, SCH.
The readout indicates the line number of the highest priority
display. For exam ple: with waveform and vector displays
both selected, a readout of F1:20 would indicate that field 1,
line 20 is displayed in waveform mode, and field 1, line 21 is
displayed in vector mode.
In a waveform display, the selected line is displayed first in a
two-line sweep, and brightened in a field sweep.
When line select is enabled, the rear-panel
PIX MON output
highlights the selected line on the picture m onitor display.
