set port vlan

7-8 802.1Q VLAN Configuration

set port vlan

UsethiscommandtoconfigurethePVID(portVLANidentifier)foroneormoreports.

Syntax

set port vlan port-string pvid [modify-egress | no-modify-egress]

Parameters

Defaults

None.

Mode

Switchcommand,read‐write.

Usage

ThePVIDisusedtoclassifyuntaggedframesastheyingressintoagivenport.

Example

Thisexampleshowshowtoaddge.1.10totheportVLANlistofVLAN4(PVID4).

D2(su)->set vlan create 4

D2(su)->set port vlan ge.1.10 4 modify-egress

clear port vlan

Usethiscommandtoresetaport’s802.1QportVLANID(PVID)tothehostVLANID1.

Syntax

clear port vlan port-string

Parameters

port‐string Specifiestheport(s)forwhichtoconfigureaVLANidentifier.Foradetailed

descriptionofpossibleport‐stringvalues,referto“PortStringSyntaxUsed

intheCLI”onpage 4‐1.

pvid SpecifiestheVLANIDoftheVLANtowhichport(s)willbeadded.

modify‐egress (Optional)Addsport(s)

toVLANʹsuntaggedegresslistandremovesthem

fromotheruntaggedegresslists.

no‐modify‐egress (Optional)Doesnotpromptforormakeegresslistchanges.

Note: The following command will reset the specified port’s egress status to tagged. To set the

specified ports back to the default egress status of untagged, you must issue the set port vlan

command as described on page 7-8.

port‐string Specifiestheport(s)toberesettothehostVLANID1.Foradetailed

descriptionofpossibleport‐stringvalues,referto“PortStringSyntaxUsed

intheCLI”onpage 4‐1.
