set rmon filter

13-18 RMON Configuration

Parameters

Defaults

Ifnooptionsarespecified,informationforallfilterentrieswillbedisplayed.

Mode

Switchcommand,read‐only.

Example

ThisexampleshowshowtodisplayallRMONfilterentriesandchannelinformation:

D2(rw)->show rmon filter

Index= 55508 Channel Index= 628 EntryStatus= valid

----------------------------------------------------------

Data Offset 0 PktStatus 0

PktStatusMask 0 PktStatusNotMask 0

Owner ETS,NAC-D

-----------------------------

Data

ff ff ff ff ff ff

-----------------------------

DataMask

ff ff ff ff ff ff

-----------------------------

DataNotMask

00 00 00 00 00 00

set rmon filter

UsethiscommandtoconfigureanRMONfilterentry.

Syntax

set rmon filter index channel-index [offset offset] [status status] [smask smask]

[snotmask snotmask] [data data] [dmask dmask] [dnotmask dnotmask] [owner owner]

Parameters

indexindex|

channelchannel

(Optional)Displaysinformationaboutaspecificfilterentry,oraboutall

filterswhichbelongtoaspecificchannel.

index Specifiesanindexnumberforthisentry.Anentrywillautomaticallybe

createdifanunusedindexnumberischosen.Maximumnumberof

entriesis10.Maximumvalueis65535.

channel‐index Specifiesthechanneltowhichthisfilterwillbeapplied.

offsetoffset (Optional)Specifiesanoffsetfromthebeginning

ofthepackettolookfor

matches.

statusstatus (Optional)Specifiespacketstatusbitsthataretobematched.

smasksmask (Optional)Specifiesthemaskappliedtostatustoindicatewhichbitsare

significant.

snotmasksnotmask (Optional)Specifiestheinversionmaskthatindicateswhichbitsshould

besetornotset

datadata (Optional)Specifies

thedatatobematched.
