set cos port-config

9-22 Policy Classification Configuration

Example

ThisexampleshowshowtoshowallCoSsettings:

D2(su)->show cos settings

CoS Index Priority ToS IRL

--------- ---------- ------- -----

0 0 * *

1 1 * *

2 2 * *

3 3 * *

4 4 * *

5 5 * *

6 6 * *

7 7 * *

set cos port-config

Usethiscommandtocreateaportgroupforinboundratelimitingandaddorremoveportsfrom

thegroup.

Syntax

set cos port-config irl group-type-index [name name] [ports port-list] [append] |

[clear]

Parameters

Defaults

None.

Mode

Switchcommand,read‐write.

Usage

CoSIRLportgroupsareidentifiedbygroupnumberandthetypeofportsinthegroup,inthe

formofgroup#.port‐type.TheIRLportgroup0.0existsbydefault.Thisdefaultportgroupcannot

beremovedandallphysicalportsinthesystemareassignedtoit.Up

tosevenadditionalport

irl Specifiesthatthisisan inboundratelimiting(IRL)portgroup.

group‐type‐index Specifiesaninboundratelimitingportgroup/typeindex.Validentries

areintheformofgroup#.port‐type.

Validvaluesforgroup#canrangefrom0to7.Validvaluesforport‐type

can

rangefrom0to1,althoughonlyporttype0iscurrentlysupported.

Forexample,portgroup3wouldbespecifiedas3.0.

namename (Optional)Userdefinednameforthegroup.

portsport‐list (Optional)Portsassignedtothegroup.Allportsmustbeofthesameport

type

(FastEthernet,GigabitEthernet).

append (Optional)Append(add)theportstotheportsthatarealreadyinthe

group.

clear (Optional)Clearthegivenportsfromthoseassignedtothe group.
