IBM AA-RWF3A-TE Switch User Manual



Scale:
1/4" = 1"
32 36 33 37 34 38 35 39
0 4 1 5 2 6 3 7
40 44 41 45 42 46 43 47
8 12 9 13 10 14 11 15
48 52 49 53 50 54 51 55
16 20 17 21 18 22 19 23
56 60 57 61 58 62 59 63
24 28 25 29 26 30 27 31
!
IOIOI
32 36 33 37 34 38 35 39
0 4 1 5 2 6 3 7
!
IOIOI
25183a
7 8
9
1
4
5 6 10 11 122 3
1. System Status LED 2. System Power LED
3. Serial port 4. Ethernet port
5. Ethernet Speed LE D 6. Ethernet Link LED
7. Port 0 Status LED
8. Port 4 Status LED
9. Ports 0 through 7
10. Port 32 Status LED
11. Port 36 Status LED 12. F C ports 32 39
Figure 26 4/64 SAN Switch port side LEDs
80
Managing SAN Switches
