Configuring the AP
AP-4131 Access Point Product Reference Guide 147
11. Under the function heading Use XMODEM to Update Access Point's: select
Firmware and HTML File.
12. Press ENTER.
Selecting Firmware and HTML File downloads the files separately. Ensure both
files are located in the same directory before the download begins.
13. At the confirmation prompt, press Y to display:
Downloading firmware using XMODEM.
Send firmware with XMODEM now ...
dsap3_fw.bin and dsapt3htm.bin are the files for a 4131 model access
point.
When using Xmodem, verify the accuracy of the file before a send. An
incorrect file can render the AP inoperable.
14. From the emulation program menu bar, select Transfer.
15. Select Send File.
16. Select Browse and locate the file(s).
17. Select XModem protocol from the drop down list.
18. Click Send.
The terminal or PC displays the transfer process through a progress bar.
19. If downloading both the firmware and HTML files, the screen flashes:
Downloading HTML file using XMODEM.
Send HTML file with XMODEM now ...
If downloading both files, repeat the steps beginning at step 13 to
download the next file and avoid a transfer time-out error. If not,
continue to step 20.
