2. PRINTER SETUP ENGLISH VERSION EO1-33089
2.6 Printer Setting
E2-27
2.6.7 Dump Mode Setting
In the Dump Mode, data in the receive buffer are printed. Data are
expressed in hexadecimal values. This operation allows verification of
the programming commands or debug of the program.
(1) BUFFER
This parameter is to choose the receive buffer to dump.
• RS-232C RS-232C receive buffer
• CENTRONICS Centronics receive buffer
• LAN Network I/F receive buffer
• BASIC1 BASIC Interpreter:
I/F → Interpreter buffer
• BASIC2 BASIC Interpreter:
Interpreter buffer → I/F
• USB USB receive buffer
• RFID RFID receive buffer
(2) DUMP LIST
This parameter is to choose the output destination.
• USB MEMORY Saves in the USB memory. → c
• PRINT Prints out → d
c When USB MEMORY is selected:
A file is automatically created in the USB memory and named in the
following format based on the printer model and saved date.
/ATA0/DUMP/B-EX4T1_DUMP_1007291030.BIN
(e.g. B-EX4T Type1, 10:30, July 29, 2010)
d When PRINT is selected:
Choose a printing method.
• ON DEMAND Prints 166 lines of data (approx. 50 cm), then
stops. Subsequent data is printed when the
[ENTER] key is pressed.
• ALL Prints all data in the receive buffer.
USER SYSTEM MODE
<5>BASIC
<6>Z-MODE
<7>AUTO CALIB
<8>DUMP MODE
NOTE:
I
f a file with the same name
already exists in the USB
memory, it will be overwritten.
