6. PRINTER SPECIFICATIONS ENGLISH VERSION EO1-33089
6. PRINTER SPECIFICATIONS
E6- 1
6. PRINTER SPECIFICATIONS
This section describes the printer specifications.
Model
Item
B-EX4T-GS12-QM-R/CN-R B-EX4T-TS12-QM-R/CN-R
Dimension (W x D x H) 278 mm x 460 mm x 310 mm (10.9” x 18.1” x 12.2”)
Weight (kg) 17 kg
Operating temperature range 5 degC to 40 degC (40 degF to 104 degF)
Relative humidity 25% to 85% RH (no condensation)
Power supply Universal switching power source AC 100 V to 240 V, 50/50 Hz +/- 10%
Input voltage AC100 V to 240 V, 50/60 Hz +/- 10%
During a print job* 116W 0.59A
During stand-by 15W or less
Power
Consumption
During sleep mode 5.7W 0.09A
Resolution 8 dots/mm (203 dpi) 12 dots/mm (305 dpi)
Printing method Thermal transfer or Thermal direct
Printing speed 76.2 mm/sec. (3 inches/sec.)
152.4 mm/sec. (6 inches/sec.)
254.0 mm/sec. (10 inches/sec.)
304.8 mm/sec. (12 inches/sec.)
355.6 mm/sec. (14 inches/sec.)
76.2 mm/sec. (3 inches/sec.)
127.0 mm/sec. (5 inches/sec.)
203.8 mm/sec. (8 inches/sec.)
254.0 mm/sec. (10 inches/sec.)
304.8 mm/sec. (12 inches/sec.)
355.6 mm/sec. (14 inches/sec.)
Available media width (including
backing paper)
25.0 mm to 120 mm (0.98 inches to 4.72 inches)
Effective print width (max.) 104.0 mm (4.1 inches)
Issue mode Batch
Strip (Strip mode is enabled only when the optional Strip Module is
installed.)
Cut (Cut mode is enabled only when the optional Cutter Module is
installed.)
LCD Message display Graphic type 128 x 64 dots
*: While 20% slant lines are printed in the specified format.
