Stylus C40UX/C40SX/C20UX/C20SX Revision A
Disassembly and Assembly Disassembly 61
4.2 Disassembly
The flowchart below shows step-by-step disassembly procedures. When disassembling
each unit, refer to the page number shown in the figure.
Figure 4-1. Disassembling Flowchart
Upper housing
removal
Page 62
ASF unit
removal
PS unit
removal
MAIN board
removal
LD unit
removal
CR Motor
removal
Printhead unit
removal
Paper eject
roller removal
Page 63
Page 65
Page 70
Page 71
Page 66
Page 73Page 68
Waste ink pad
removal
Page 73
