Initial Setup menu
The Initial Setup menu contains the sub-menus shown:
●
Networking and I/O menu
●
Fax Setup menu
●
E-mail Setup menu
NOTE: Values shown with "(default)" are the factory-default values. Some menu items have no default.
Networking and I/O
Table 2-9 Networking and I/O
Menu item Sub-menu item Values Description
I/O Timeout Select a value in the
range. The factory default
setting is 15 seconds.
I/O timeout refers to the elapsed time before a print job
fails. If the stream of data that the device receives for
a print job gets interrupted, this setting indicates how
long the device will wait before it reports that the job
has failed.
Parallel Input
NOTE: This item
appears only if an EIO
accessory is installed.
High Speed No
Yes (default)
Use the High Speed setting to configure the speed that
the parallel port uses to communicate with the host.
Advanced Functions Enabled (default)
Disabled
Use the Advanced Functions setting to enable or
disable bidirectional parallel communication.
Embedded Jetdirect See Table 2-10 Jetdirect menus on page 32 for the list of options.
EIO <X> Jetdirect
Table 2-10 Jetdirect menus
Menu item Sub-menu item Sub-menu item Values and Description
TCP/IP Enable Off: Disable the TCP/IP protocol.
On (default): Enable the TCP/IP protocol.
Host Name An alphanumeric string, up to 32 characters, used to
identify the device. This name is listed on the
HP Jetdirect configuration page. The default host name
is NPIxxxxxx, where xxxxxx is the last six digits of the
LAN hardware (MAC) address.
32 Chapter 2 Control Panel ENWW
