MultiProcessor Specification
4-16 Version 1.4
Table 4-12. Local Interrupt Entry Fields
Field
Offset (in
bytes:bits)
Length
(in bits) Description
ENTRY TYPE 0 8 Entry type 4 identifies a local interrupt
entry.
INTERRUPT TYPE 1 8 See Table 4-11 for values
PO 2:0 2 Polarity of APIC local input signals:
00 = Conforms to
specifications of bus
(for example, EISA is
active-low for level
triggered interrupts)
01 = Active high
10 = Reserved
11 = Active low
Must be 00 if the 82489DX is used.
EL 2:2 2 Trigger mode of APIC local input signals:
00 = Conforms to
specifications of bus
(for example, ISA is
edge triggered)
01 = Edge-triggered
10 = Reserved
11 = Level-triggered
SOURCE BUS ID 4 8 Identifies the bus from which the interrupt
signal came.
SOURCE BUS IRQ 5 8 Identifies the interrupt signal from the
source bus. Values are mapped onto
source bus signals, starting from zero. A
value of 0, for example, would indicate
IRQ0 of an ISA bus. See Section D.3 for
PCI bus semantics.
DESTINATION LOCAL APIC ID 6 8 Identifies the local APIC to which the
signal is connected. If the ID is 0FFh, the
signal is connected to all local APICs.
DESTINATION LOCAL APIC
LINTIN#
7 8 Identifies the LINTIN
n
pin to which the
signal is connected, where n = 0 or 1.
