Chapter 2: Installation Requirements
LAN Installation: Ethernet
22
Psion Teklogix 9160 G2 Wireless Gateway User Manual
2.2.3 LAN Installation: Ethernet
The 9160 G2 is a high-performance Access Point that supports 100Mb/s Fast Ether-
net LANs, as well as 10Mb/s, with both full and half duplex operation. It comes
equipped with: a 10BaseT/100BaseT card (using a category-5 twisted pair cable, an
RJ-45 connector, running at a rate of 10 or 100Mb/s). For port pinouts, please refer
to Appendix B: “Port Pinouts And Cable Diagrams”.
Note: The 9160 G2 does not support any connection type other than Ethernet
10BaseT and 100BaseT.
2.2.3.1 Ethernet Cabling
The maximum cable segment length allowed between repeaters for the 9160 G2
(10BaseT/100BaseT Ethernet cabling) is 100 m.
2.2.4 Status Indicators (LEDs)
The high-performance 9160 G2 has six status indicators on the front of the enclo-
sure, as shown in Figure 2.2 on page 21. The numbered and coloured LEDs on the
front of the unit indicate the operating status for each port, as described in Table 2.1.
LED
Number
Name Function Colour
1 Ethernet link Link indicator for 10BaseT/100BaseT:
ON = good link; OFF = no link
yellow
*
2 Ethernet activity Ethernet LAN activity (Rx/Tx) green
3 1st 802.11 radio status 1st 802.11 radio activity (Rx/Tx) green
4 2nd 802.11 radio status 2nd 802.11 radio activity (Rx/Tx) green
5 NB radio status NB radio activity (Rx/Tx) green
6 Power LED On solid = Unit powered
LED Off = No power to unit
green
*
LED 1 colour shows orientation of LEDs when viewed from a distance.
Table 2.1 9160 G2 LED Functions: Front Enclosure
