EMAC Module Registers
www.ti.com
5.21 Receive Multicast/Broadcast/Promiscuous Channel Enable Register
(RXMBPENABLE)
The receive multicast/broadcast/promiscuous channel enable register (RXMBPENABLE) is shown in
Figure 59 and described in Table 58.
Figure 59. Receive Multicast/Broadcast/Promiscuous Channel Enable Register (RXMBPENABLE)
31 30 29 28 27 25 24
Reserved RXPASSCRC RXQOSEN RXNOCHAIN Reserved RXCMFEN
R-0 R/W-0 R/W-0 R/W-0 R-0 R/W-0
23 22 21 20 19 18 16
RXCSFEN RXCEFEN RXCAFEN Reserved RXPROMCH
R/W-0 R/W-0 R/W-0 R-0 R/W-0
15 14 13 12 11 10 8
Reserved RXBROADEN Reserved RXBROADCH
R-0 R/W-0 R-0 R/W-0
7 6 5 4 3 2 0
Reserved RXMULTEN Reserved RXMULTCH
R-0 R/W-0 R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 58. Receive Multicast/Broadcast/Promiscuous Channel Enable Register (RXMBPENABLE)
Field Descriptions
Bit Field Value Description
31 Reserved 0 Reserved
30 RXPASSCRC Pass receive CRC enable bit
0 Received CRC is discarded for all channels and is not included in the buffer descriptor packet
length field.
1 Received CRC is transferred to memory for all channels and is included in the buffer descriptor
packet length.
29 RXQOSEN Receive quality of service enable bit
0 Receive QOS is disabled.
1 Receive QOS is enabled.
28 RXNOCHAIN Receive no buffer chaining bit
0 Received frames can span multiple buffers.
1 The Receive DMA controller transfers each frame into a single buffer, regardless of the frame or
buffer size. All remaining frame data after the first buffer is discarded. The buffer descriptor buffer
length field will contain the entire frame byte count (up to 65535 bytes).
27-25 Reserved 0 Reserved
24 RXCMFEN Receive copy MAC control frames enable bit. Enables MAC control frames to be transferred to
memory. MAC control frames are normally acted upon (if enabled), but not copied to memory. MAC
control frames that are pause frames will be acted upon if enabled in MACCONTROL, regardless of
the value of RXCMFEN. Frames transferred to memory due to RXCMFEN will have the CONTROL
bit set in their EOP buffer descriptor.
0 MAC control frames are filtered (but acted upon if enabled).
1 MAC control frames are transferred to memory.
23 RXCSFEN Receive copy short frames enable bit. Enables frames or fragments shorter than 64 bytes to be
copied to memory. Frames transferred to memory due to RXCSFEN will have the FRAGMENT or
UNDERSIZE bit set in their EOP buffer descriptor. Fragments are short frames that contain CRC /
align / code errors and undersized are short frames without errors.
0 Short frames are filtered.
1 Short frames are transferred to memory.
