www.ti.com
EMAC Module Registers
Table 67. MAC Status Register (MACSTATUS) Field Descriptions (continued)
Bit Field Value Description
15-12 RXERRCODE 0-Fh Receive host error code. These bits indicate that EMAC detected receive DMA related host errors.
The host should read this field after a host error interrupt (HOSTPEND) to determine the error. Host
error interrupts require hardware reset in order to recover.
0 No error
1h Reserved
2h Ownership bit not set in SOP buffer
3h Reserved
4h Zero buffer pointer
5h-Fh Reserved
11 Reserved 0 Reserved
10-8 RXERRCH 0-7h Receive host error channel. These bits indicate which receive channel the host error occurred on.
This field is cleared to 0 on a host read.
0 The host error occurred on receive channel 0
1h The host error occurred on receive channel 1
2h The host error occurred on receive channel 2
3h The host error occurred on receive channel 3
4h The host error occurred on receive channel 4
5h The host error occurred on receive channel 5
6h The host error occurred on receive channel 6
7h The host error occurred on receive channel 7
7-3 Reserved 0 Reserved
2 RXQOSACT Receive Quality of Service (QOS) active bit. When asserted, indicates that receive quality of service
is enabled and that at least one channel freebuffer count (RXnFREEBUFFER) is less than or equal
to the RXFILTERLOWTHRESH value.
0 Receive quality of service is disabled.
1 Receive quality of service is enabled.
1 RXFLOWACT Receive flow control active bit. When asserted, at least one channel freebuffer count
(RXnFREEBUFFER) is less than or equal to the channel's corresponding RXnFILTERTHRESH
value.
0 Receive flow control is inactive.
1 Receive flow control is active.
0 TXFLOWACT Transmit flow control active bit. When asserted, this bit indicates that the pause time period is being
observed for a received pause frame. No new transmissions will begin while this bit is asserted,
except for the transmission of pause frames. Any transmission in progress when this bit is asserted
will complete.
0 Transmit flow control is inactive.
1 Transmit flow control is active.
113
SPRUFL5B–April 2011 EMAC/MDIO Module
