EMAC Module Registers
www.ti.com
5.7 Transmit Interrupt Status (Unmasked) Register (TXINTSTATRAW)
The transmit interrupt status (unmasked) register (TXINTSTATRAW) is shown in Figure 45 and described
in Table 44.
Figure 45. Transmit Interrupt Status (Unmasked) Register (TXINTSTATRAW)
31 16
Reserved
R-0
15 8
Reserved
R-0
7 6 5 4 3 2 1 0
TX7PEND TX6PEND TX5PEND TX4PEND TX3PEND TX2PEND TX1PEND TX0PEND
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 44. Transmit Interrupt Status (Unmasked) Register (TXINTSTATRAW) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reserved
7 TX7PEND 0-1 TX7PEND raw interrupt read (before mask)
6 TX6PEND 0-1 TX6PEND raw interrupt read (before mask)
5 TX5PEND 0-1 TX5PEND raw interrupt read (before mask)
4 TX4PEND 0-1 TX4PEND raw interrupt read (before mask)
3 TX3PEND 0-1 TX3PEND raw interrupt read (before mask)
2 TX2PEND 0-1 TX2PEND raw interrupt read (before mask)
1 TX1PEND 0-1 TX1PEND raw interrupt read (before mask)
0 TX0PEND 0-1 TX0PEND raw interrupt read (before mask)
