6-5
When the desired size of paper is not set in any of the drawers, or when you want to make copies on A3-
wide or non-standard sized paper, use the sheet bypass.
The modes below are available even in bypass copying if the paper size is specified:
- automatic paper selection - automatic magnification selection - duplex
- edge erase - image shift - book centre erase - dual-page
- full image - 2 IN 1 / 4 IN 1 - trimming/masking - mirror image
- centring - image repeat - staple sorting - magazine sort
- saddle stitching - hole punching
In these cases, the setting procedures of the following two types of paper are different:
- Bypass copying on standard size and A3-wide paper
Page 6-7
- Bypass copying on non-standard size paper
Page 6-9
If you want to make copies on thin paper, thick paper, OHP film, sticker label, special paper, etc., make
bypass copies.
Page 6-11, 6-12
* You can also set THIN paper (64~79g/m
2
), THICK1 paper (106~163g/m
2
) and OHP films in the drawers.
Page 2-7
3. BYPASS COPYING
- Refer to the table below and select the mode corresponding to the paper that has been set. Otherwise,
paper jams may result or the image quality could deteriorate.
- The number of sheets that can be set at a time differs depending on the paper type. Setting more than the specified
number of sheets at a time may cause copier failure or the paper jams. Be sure to set within the specified range.
- It takes from 30 to 60 seconds to switch modes among “PLAIN”, “THICK1”, “THICK2”, “THICK3”, “THICK4”,
“SPECIAL” and “OHP FILM” for adjustment, and from 30 to 120 seconds between “THIN” and other modes.
Bypass Copy Mode
- If the BYPASS MISFEED symbol flashes, pull out the paper and place it on the sheet bypass again.
Page 9-13
- When copying is finished, the lamp of the FUNCTION CLEAR key lights. Either press the FUNCTION
CLEAR key, or wait 45 seconds before the bypass copying mode automatically returns to the default mode.
THIN (64-79g/m
2
)
PLAIN (80-105g/m
2
)
THICK1 (106-163g/m
2
)
THICK2 (164-209g/m
2
)
THICK3 (210-256g/m
2
)
THICK4 (257-280g/m
2
)
Sticker labels (THICK2)
Special paper
OHP FILM
Maximum Capacity
130 sheets
115 sheets (90g/m
2
)
100 sheets (100g/m
2
)
60 sheets (120g/m
2
)
60 sheets (160g/m
2
)
40 sheets (200g/m
2
)
40 sheets (220g/m
2
)
40 sheets (250g/m
2
)
40 sheets
40 sheets
40 sheets
40 sheets
Corresponding Paper Type
Paper Size
(Standard size)
A/B format: A3,A4,A4-R,A5-R,A6-R,B4,B5,B5-R,
FOLIO(210x330mm),A3-wide(305x457mm)
LT format: LD(11”x17”), LG(8
1
/
2
”
x14”),
LT(11”x8
1
/
2
”
), LT-R(8
1
/
2
”
x11”), ST-R(5
1
/
2
”
x8
1
/
2
”
),
COMP(10
1
/
8
”
x14”), 13”LG(8
1
/
2
”x13”),
8.5”SQ(8
1
/
2
”x8
1
/
2
”)
(Non-standard size)
Length: 100-305mm; Width: 148-457mm
(Standard size)
A4
* The copier stops its operation when the paper set on the bypass guide has run out even if there is the
same size of copy paper in the drawer.
* When the finisher (optional) is installed, the images may not output easily according to the environment.
(Standard size)
A3, A4, A4-R
