BEFORE MAKING COPIES
1. DESCRIPTION OF THE DIGITAL COLOUR COPIER AND THE OPTIONAL EQUIPMENT
Main Components
Original cover
(Optional)
Original glass
Key copy
counter slot
Power switch
Bypass guide
Feed side cover
Paper size indicator
Original scales
Control panel
Drawers*1
Transfer belt unit
Fuser unit
Operator’s manual pocket
(Back side)
Toner cartridges
Right-hand front cover
Electrophotographic unit
Transfer belt unit
Transfer belt unit knob
Used toner bag
(container)
Left-hand
front cover
Fuser unit
*1......2 drawers are standard equipment. When the automatic duplexer (optional) is installed
in the uppermost drawer, the 2nd to the 4th drawers are for paper feeding (the 4th is an
option).
Exit cover
(Left side)
