Introduction
1
1200V Modero Video Touch Panels
Introduction
AMX has taken a great leap forward with the release of their new 1200V-Series of Modero touch panels.
These panels offer the ability to display Composite video, 802.11g communication, and USB support for
extended input devices, and panel programming via a mini-USB port. The new G4 graphics and Video
technology is supported by the release of the latest TPDesign4 Touch Panel Design Program. These
video-capable panels support several video formats: NTSC, SECAM, and PAL (Color Active (CA)
panels don’t support video).
Each 1200V-Series panels have been pre-installed with 2 antennas which can be later used to
configure each panel type for wireless communication (via an optional NXA-80211G wireless
mini-PCI card).
Modero Video Touch Panels (1200V-Series)
The new and enhanced line of 12" Modero Touch Panel (NXT/NXD-1200V) represent the next step in
video-capable panels and departs from the previously popular CA version. In addition to
Composite/S-Video support (does not support Component RGB signals), the new 1200V panels feature
dual USB connectivity for mouse and keyboard, and antennas, the use of a mini-USB port for panel
programming and a complete departure from the use of an ICSNet connector for communication. These
panels include a built-in microphone, left/right speakers, audio/headphone connector, and an included
audio/video breakout box.
Table Top models use AMX’s exclusive SmoothTilt
®
technology for effortless adjustment of the
viewing angle.
Each panel is sold only as part of a 1200V Kit which includes both a panel and an
NXA-AVB/ETHERNET Audio/Video Breakout Box (FG2254-10). This box facilitates the installation
and distribution of video, data, and audio to Modero touch panels located up to 200 feet (60.96 m) from
the breakout box. These panels are ideally suited for displaying full motion video and audio with overlay
graphics for applications with demanding visual requirements. The following is a listing of the currently
available 1200V panels:
1200-V Modero Video Touch Panels
NXD-1200V
(FG2251-60K)
12" Modero Video WallMount Touch Panel Kit
(includes both an NXD panel and an NXA-AVB/ETHERNET A/V Breakout Box).
NXT-1200V
(FG2250-60K)
12" Modero Video Table Top Touch Panel Kit
(includes both an NXD panel and an NXA-AVB/ETHERNET A/V Breakout Box).
FIG. 1
Sample 1200V Video Touch Panels (front views)
Sample
Sample
NXD-1200V
(front view)
NXT-1200V
(front view)
