Installation Procedures: NXD-1200V Panels
33
1200V Modero Video Touch Panels
Installation Procedures: NXD-1200V Panels
NXT panels are mounted onto flat (horizontal) surfaces in either a stand-alone or combo (NXT atop an
NXA-BASE/B battery base) configuration. NXD panels are installed into either a pre-wall surface (using
a CB-TP12 conduit/wallbox) or a solid surface (using either solid surface or drywall screws).
Unpacking the Panel
1. Inspect and confirm the contents of the shipment box to verify that you have all specified parts.
Refer to the Specifications sections on page 2 for more information about included accessories and
other AMX equipment.
2. Carefully remove the panel from the shipping box.
3. Carefully peel the protective plastic cover from the LCD.
Installing the Internal Components
Installation of the internal components such as the upgraded Compact Flash memory and
NXA-PCI80211G Wireless card are described in detail within the following sections:
Step 2: Install the 802.11g mini-PCI Wireless Card section on page 19.
Step 3: Install the Compact Flash Memory Card upgrade section on page 21.
Upgrading to the MB-TP12 VESA Mounting Kit
Upgrading the existing back box with the new VESA Mounting Kit on the 12" (FG031-50) panel
requires 3 main processes:
Removing the pre-existing back box and installing the new VESA back box.
Threading cables through the strain relief grommet opening in the rear plastic cover.
Finalizing the installation of the NXD (with VESA back box and cables) into the plastic cover,
securing both components, and finalizing the strain relief grommet installation.
It is recommended that if you are planning on upgrading your panel components
(flash card and wireless), you do so before beginning any panel installations.
If the protective plastic LCD cover is not removed, the panel may not respond
properly to touch points on the LCD or allow proper screen calibration.
Only overall dimensions and FG product numbers are different.
The new MB-TP Universal VESA Mounting Box uses a standard VESA installation
pattern of 75 mm between holes. VESA mounts that conform to this pattern can be
used on the MB-TP Housing.
